CLOCK OSCILLATOR
Select any parameter below to start.
Datasheet Part Number Frequency Range Supply Voltage (V)
Output Logic
Dimensions L * W / type
Height (mm)
Operating Temperature (°C)
Spread Percentage (%)
HPJK226
HPJK226 2520 2.5V Ultra Low Jitter Differential LVPECL SMD Crystal Oscillator
100 ~ 250MHz 2.5 LVPECL 2.5 x 2.0 1.0 -40 to +85
HDQN536
HDQN536 5032 3.3V Low Jitter Differential LVDS SMD Crystal Oscillator
150 ~ 1500MHz 3.3 LVDS 5.0 x 3.2 1.2 -40 to +85
HTQN326
HTQN326 3225 2.5V Low Jitter CMOS SMD Crystal Oscillator
150 ~ 250MHz 2.5 CMOS 3.2 x 2.5 1.0 -40 to +85
HPQN576
HPQN576 7050 3.3V Low Jitter Differential LVPECL SMD Crystal Oscillator
150 ~ 1500MHz 3.3 LVPECL 7.0 x 5.0 1.8 -40 to +85
HPQN576
HPQN576 7050 2.5V Low Jitter Differential LVPECL SMD Crystal Oscillator
150 ~ 1500MHz 2.5 LVPECL 7.0 x 5.0 1.8 -40 to +85
HPQN536
HPQN536 5032 3.3V Low Jitter Differential LVPECL SMD Crystal Oscillator
150 ~ 1500MHz 3.3 LVPECL 5.0 x 3.2 1.2 -40 to +85
HPQN536
HPQN536 5032 2.5V Low Jitter Differential LVPECL SMD Crystal Oscillator
150 ~ 1500MHz 2.5 LVPECL 5.0 x 3.2 1.2 -40 to +85
HPQN326
HPQN326 3225 3.3V Low Jitter Differential LVPECL SMD Crystal Oscillator
150 ~ 1500MHz 3.3 LVPECL 3.2 x 2.5 1.0 -40 to +85
HPQN326
HPQN326 3225 2.5V Low Jitter Differential LVPECL SMD Crystal Oscillator
150 ~ 1500MHz 2.5 LVPECL 3.2 x 2.5 1.0 -40 to +85
HDQN576
HDQN576 7050 3.3V Low Jitter Differential LVDS SMD Crystal Oscillator
150 ~ 1500MHz 3.3 LVDS 7.0 x 5.0 1.8 -40 to +85
HDQN576
HDQN576 7050 2.5V Low Jitter Differential LVDS SMD Crystal Oscillator
150 ~ 1500MHz 2.5 LVDS 7.0 x 5.0 1.8 -40 to +85
HPJK326
HPJK326 3225 3.3V Ultra Low Jitter Differential LVPECL SMD Crystal Oscillator
100 ~ 250MHz 3.3 LVPECL 3.2 x 2.5 1.0 -40 to +85
HPJK536
HPJK536 5032 3.3V Ultra Low Jitter Differential LVPECL SMD Crystal Oscillator
100 ~ 250MHz 3.3 LVPECL 5.0 x 3.2 1.2 -40 to +85
HPJK536
HPJK536 5032 2.5V Ultra Low Jitter Differential LVPECL SMD Crystal Oscillator
100 ~ 250MHz 2.5 LVPECL 5.0 x 3.2 1.2 -40 to +85
HPJK576
HPJK576 7050 2.5V Ultra Low Jitter Differential LVPECL SMD Crystal Oscillator
100 ~ 250MHz 2.5 LVPECL 7.0 x 5.0 1.8 -40 to +85
Total: 322 entries
