CLOCK OSCILLATOR
Select any parameter below to start.
Datasheet Part Number Frequency Range Supply Voltage (V)
Output Logic
Dimensions L * W / type
Height (mm)
Operating Temperature (°C)
Spread Percentage (%)
HPQF326
HPQF326 3225 2.5V Quick-Turn Programmable Differential LVPECL SMD Crystal Oscillator
10 ~ 1500MHz 2.5 LVPECL 3.2 x 2.5 1.0 -40 to +85
HDQF576
HDQF576 7050 3.3V Quick-Turn Programmable Differential LVDS SMD Crystal Oscillator
10 ~ 1500MHz 3.3 LVDS 7.0 x 5.0 1.8 -40 to +85
HDQF576
HDQF576 7050 2.5V Quick-Turn Programmable Differential LVDS SMD Crystal Oscillator
10 ~ 1500MHz 2.5 LVDS 7.0 x 5.0 1.8 -40 to +85
HDQF536
HDQF536 5032 3.3V Quick-Turn Programmable Differential LVDS SMD Crystal Oscillator
10 ~ 1500MHz 3.3 LVDS 5.0 x 3.2 1.2 -40 to +85
HDQF536
HDQF536 5032 2.5V Quick-Turn Programmable Differential LVDS SMD Crystal Oscillator
10 ~ 1500MHz 2.5 LVDS 5.0 x 3.2 1.2 -40 to +85
HDQF326
HDQF326 3225 3.3V Quick-Turn Programmable Differential LVDS SMD Crystal Oscillator
10 ~ 1500MHz 3.3 LVDS 3.2 x 2.5 1.0 -40 to +85
HDQF326
HDQF326 3225 2.5V Quick-Turn Programmable Differential LVDS SMD Crystal Oscillator
10 ~ 1500MHz 2.5 LVDS 3.2 x 2.5 1.0 -40 to +85
HTQN576
HTQN576 7050 3.3V Low Jitter CMOS SMD Crystal Oscillator
150 ~ 250MHz 3.3 CMOS 7.0 x 5.0 1.8 -40 to +85
HTQN576
HTQN576 7050 2.5V Low Jitter CMOS SMD Crystal Oscillator
150 ~ 250MHz 2.5 CMOS 7.0 x 5.0 1.8 -40 to +85
HTQN536
HTQN536 5032 3.3V Low Jitter CMOS SMD Crystal Oscillator
150 ~ 250MHz 3.3 CMOS 5.0 x 3.2 1.2 -40 to +85
HTQN536
HTQN536 5032 2.5V Low Jitter CMOS SMD Crystal Oscillator
150 ~ 250MHz 2.5 CMOS 5.0 x 3.2 1.2 -40 to +85
HDJK326
HDJK326 3225 3.3V Ultra Low Jitter Differential LVDS SMD Crystal Oscillator
100 ~ 250MHz 3.3 LVDS 3.2 x 2.5 1.0 -40 to +85
HDJK536
HDJK536 5032 2.5V Ultra Low Jitter Differential LVDS SMD Crystal Oscillator
100 ~ 250MHz 2.5 LVDS 5.0 x 3.2 1.2 -40 to +85
HDJK536
HDJK536 5032 1.8V Ultra Low Jitter Differential LVDS SMD Crystal Oscillator
100 ~ 175MHz 1.8 LVDS 5.0 x 3.2 1.2 -40 to +85
HDJK536
HDJK536 5032 3.3V Ultra Low Jitter Differential LVDS SMD Crystal Oscillator
100 ~ 250MHz 3.3 LVDS 5.0 x 3.2 1.2 -40 to +85
Total: 322 entries
