CRYSTAL FILTER
Select any parameter below to start.
Datasheet Part Number Frequency Range Dimensions (mm)
Height (mm)
Pass Bandwidth
poles / Tandem set
49T
49T 11.5x4.5mm 8poles / 49T 4 pcs Thru-Hole Type Monolithic Crystal Filter
10.7 MHz 11.5 x 4.5 11.2 ±3.75 kHz ~ ±15 kHz 8 / 49T 4 pcs
49T
49T 11.5x4.5mm 2Poles Thru-Hole Type Monolithic Crystal Filter
10.695 ~ 10.800 MHz 11.5 x 4.5 11.2 ±3.75 kHz ~ ±15 kHz 2
MQ
MQ 7050 2Poles SMD Monolithic Crystal Filter
21.4MHz 7.0 x 5.0 1.3 ±3.75 kHz ~ ±15 kHz 2
49T
49T 11.5x4.5mm 6poles / 49T 3 pcs Thru-Hole Type Monolithic Crystal Filter
10.695 ~ 10.800 MHz 11.5 x 4.5 11.2 ±3.75 kHz ~ ±15 kHz 6 / 49T 3 pcs
49T
49T 11.5x4.5mm 8poles / 49T 4 pcs Thru-Hole Type Monolithic Crystal Filter
10.695 ~ 10.800 MHz 11.5 x 4.5 11.2 ±3.75 kHz ~ ±15 kHz 8 / 49T 4 pcs
49TMJ
49TMJ 14.7x11.5mm 2Poles Jackrt Type Monolithic Crystal Filter
10.7 MHz 14.7 x 11.5 5.2 ±3.75 kHz ~ ±15 kHz 2
49TMJ
49TMJ 14.7x11.5mm 4poles / a pair Jackrt Type Monolithic Crystal Filter
10.7 MHz 14.7 x 11.5 5.2 ±3.75 kHz ~ ±15 kHz 4 / a pair
49TMJ
49TMJ 14.7x11.5mm 2Poles Jackrt Type Monolithic Crystal Filter
10.695 ~ 10.800 MHz 14.7 x 11.5 5.2 ±3.75 kHz ~ ±15 kHz 2
49TMJ
49TMJ 14.7x11.5mm 4poles / a pair Jackrt Type Monolithic Crystal Filter
10.695 ~ 10.800 MHz 14.7 x 11.5 5.2 ±3.75 kHz ~ ±15 kHz 4 / a pair
U1
U1 7.8x3.1mm 2Poles Thru-Hole Type Monolithic Crystal Filter
21.4MHz 7.8 x 3.1 8.0 ±3.75 kHz ~ ±15 kHz 2
U1
U1 7.8x3.1mm 4poles / a pair Thru-Hole Type Monolithic Crystal Filter
21.4MHz 7.8 x 3.1 8.0 ±3.75 kHz ~ ±15 kHz 4 / a pair
U1
U1 7.8x3.1mm 6poles / U1 3 pcs Thru-Hole Type Monolithic Crystal Filter
21.4MHz 7.8 x 3.1 8.0 ±3.75 kHz ~ ±15 kHz 6 / U1 3 pcs
Total: 42 entries
